Products
A Combination Cabinet Series
Description
1. The same material as the Hairong brand, high-end and atmospheric.
2. Use large stainless steel handles, durable
3. LED lights, strong display effect, meet the user's display needs for food display.
4. Aluminum-plastic embossed liner, corrosion-resistant, longer service life than embossed aluminum liner
5. Equipped with encrypted mesh frame, convenient for users to clearly display food.
6. The tempered coated heat-reflective glass door has good insulation effect and display effect.
7. Use brake wheel device, convenient for users to use.
Product Series | Model A Cabinet Series | ||||
Model | SD/SC-400 Straight Cabinet | SD/SC-600 End Cabinet | SD/SC-700 Straight Cabinet | SD/SC-800 Straight Cabinet | SD/SC-900 Straight Cabinet |
Cabinet Color (Optional) | White (Color Code 7300)Gray (Color Code 7024) | ||||
Cabinet Frame Color & Material | Light Gray, Plastic PVC | ||||
Front Frame Material & Color | Aluminum Alloy Sandblasted Silver White | ||||
Left/Right Sliding Glass Doors | Upper: 1 panel, Lower: 1 panel | ||||
Upper/Lower Sliding Glass Doors | Upper: 2 panels, Lower: 2 panels | ||||
Lighting | White LED Light, 220V | ||||
Inner Material & Thickness | White Embossed Aluminum Plate / 0.35MM | ||||
Outer Material & Thickness | Galvanized Sheet Electrostatic Spraying / 0.45MM | ||||
Insulation Material | Cyclopentane | ||||
Insulation Thickness & Density | 75MM/38kg/m³ | ||||
Caster Size & Height | 2-inch / Height 70MM | ||||
Cooling Method | Cooling Method | ||||
Cooling Tube Material | Galvanized Tube 7.80.6 / Copper Tube 70.4 | ||||
Temperature Range (°C) | 10℃ To-24℃ | ||||
Temperature Control | Smart Lighting & Temperature Control | ||||
Caster Type | 2 Swivel / 2 Brake | 2 Swivel / 2 Brake | 2 Swivel / 2 Brake | 2 Swivel / 2 Brake | 4 Swivel / 2 Brake |
Included Net Baskets | 4 | 6 | 6 | 7 | 8 |
Included Flat Shelves | 2 | 4 | 4 | 4 | 4 |
Net Capacity (L) | 347L | 560L | 580L | 670L | 797L |
Condenser Model | Steel Wire 280 (8 Rows) | Steel Wire 320 (8 Rows) | Steel Wire 320 (8 Rows) | Steel Wire 320 (8 Rows) | Steel Wire 325 (Dual Channel) |
Condenser Fan Brand & Model | Fengyin Motor 35W Aluminum Blades | Fengyin Motor 35W Aluminum Blades | Fengyin Motor 35W Aluminum Blades | Fengyin Motor 35W Aluminum Blades | Fengyin Motor 35W Aluminum Blades |
Refrigerant Type & Charge (g) | R290/84g | R290/120g | R290/120g | R290/130g | R290/176g |
Compressor Brand & Model | Dongbei L76CU1 | Dongbei KK480CUI/Meizhi PA99HMF | Dongbei KK480CUI/Meizhi PA99HMF | Dongbei KK550CUI | Dongbei NE2168CU |
Rated Voltage (V) | 220V/50HZ | 220V/50HZ | 220V/50HZ | 220V/50HZ | 220V/50HZ |
Input Current (A) | 1.9A | 2.3A | 2.3A | 2.4A | 2.6A |
Energy Consumption (kWh) | 2.8kw.h/24h | 3.8kw.h/24h | 3.8kw.h/24h | 4.0kw.h/24h | 4.5kw.h/24h |
Total Input Power (W) | 236W | 280W | 280W | 310W | 390W |
Product Weight (kg) | 66kg | 84kg | 89kg | 94kg | 111kg |
Product Weight (kg, Packaged) | 76kg | 96kg | 102kg | 110kg | 129kg |
Product Internal Dimensions(mm) | 1095*645*570 | 1700*645*520 | 1700*645*570 | 1935*645*570 | 2340*645*570 |
Product External Dimensions(mm) | 1260*815*860 | 1860*815*800 | 1860*815*860 | 2100*815*860 | 2500*815*860 |
Product Packaging Size(mm) | 1325*880*930 | 1930*880*870 | 1930*880*950 | 2170*880*950 | 2570*880*950 |
Packaging Method | Wooden Pallet + Product + Plastic Bag + Foam + Wooden Cover + Carton + Straps | ||||
